Solar Street Light SKU: LS-SOLAR-ST01

AIO Smart Solar Street Light (80W)

Name: AIO Smart Solar Street Light (80W)
Brand: LinkSow Lighting
SKU: LS-SOLAR-ST01
Availability: InStock

The LinkSow LS-SOLAR-ST01 is an integrated all-in-one solar street light delivering 14,400 lumens at 180 lm/W. Equipped with a 120Wp grade-A monocrystalline panel, a 50Ah LiFePO4 battery pack (2,000+ deep cycles), and an intelligent MPPT charging controller, it provides reliable off-grid lighting with up to 5 rainy days of continuous autonomy.

Solar Panel

120Wp Mono Grade-A

Battery Pack

LiFePO4 50Ah 12.8V

System Efficacy

180 lm/W (14.4k lm)

Autonomy

5-7 Continuous Rainy Days

🏢 B2B Commercial Sourcing Summary

Factory MOQ 20 PCS (Sample test kits available)

Sample Dispatch 4 - 6 Business Days

Mass Production 12 - 18 Calendar Days

Battery Certs UN38.3, MSDS, Sea Freight Certified

Shipping Port Zhongshan / Shenzhen Port

Controller Protocol PIR Motion Sensor + IoT 4G/Zigbee Option

Request Factory Quotation & Samples → 💬 WhatsApp Live Sourcing

Engineering Excellence

Core Engineering Highlights & Architecture

Designed and built in China's World Lighting Capital, Guzhen, with certified Tier-1 components for rigorous international project standards.

☀️

22.5% Mono PV Integration

Top-grade monocrystalline silicon solar cells with anti-reflective glass provide rapid charging even in overcast conditions within 5-6 peak sun hours.

🔋

A-Grade LiFePO4 Battery Pack

Non-explosive lithium iron phosphate cells with smart BMS protection against over-charge, over-discharge, short-circuit, and extreme temperature.

🧠

Adaptive MPPT + Smart Dimming

Microprocessor calculates remaining battery capacity each sunset and automatically regulates output curves to ensure zero blackouts on consecutive rainy days.

🌪️

Grade-14 Typhoon Resistance

Low wind-drag streamline extruded aluminum profile tested to withstand gale force winds and harsh desert dust storms without degradation.

Comprehensive Datasheet

Full 14-Point Technical Specifications

Verifiable parameters tested in accordance with international CIE, IEC, and EN lighting laboratory standards.

Parameter Category	Engineering Specification Details (LS-SOLAR-ST01)
Model Number (SKU)	LS-SOLAR-ST01
LED Module Power	80W Bridgelux 5050 High Efficacy (180 lm/W)
Photovoltaic Solar Panel	120Wp Monocrystalline Silicon (22.5% Conversion Efficiency)
Energy Storage Battery	Deep-cycle LiFePO4 12.8V / 50Ah (640Wh capacity, >2,000 cycles)
Luminous Flux Output	14,400 lm Peak Output (Time-profile dimmable)
Color Rendering Index (CRI)	Ra ≥ 75 (Clear optical contrast on roads)
Color Temperature (CCT)	4000K Neutral White / 6000K Daylight White
Solar Charge Controller	Patented MPPT Controller with 98% tracking efficiency & PIR sensor
Body Housing Material	Extruded & Die-cast Aviation Aluminum Alloy 6063
Ingress & Wind Rating	IP66 Waterproof / Anti-Typhoon Grade 14 (up to 55 m/s)
Lighting Working Modes	Dusk-to-dawn, 4-stage smart power reduction, PIR human radar trigger
Operating Temperature	-20°C to +65°C (Wide thermal operating envelope)
Certifications & Shipping	CE, RoHS, CB, UN38.3, MSDS, Dangerous Goods Safe Sea Packing
Warranty Terms	3 Years Complete Unit, 5 Years Battery Cycle Life Warranty

Photometric Distribution

Optical Engineering & Dialux Simulation Guide

Featuring a 140° × 70° specialized solar batwing lens, the fixture casts a wide oval footprint along the street, allowing 6m-9m mounting heights with pole spacings up to 25-30m without dark zones.

Mounting Height	Recommended Spacing	Application Target Area	Achieved Average Illuminance
6 - 7 Meters	20 - 25 Meters	Single / Dual Lane	20 - 25 Lux
8 - 9 Meters	25 - 30 Meters	Dual Lane Rural Highway	18 - 22 Lux
9 - 10 Meters	28 - 35 Meters	Industrial Perimeter Road	15 - 20 Lux

Real-World Applications

Recommended Project Environments

From extreme climatic conditions to luxury indoor spaces, verified across global installations.

Rural & Off-Grid Roadways

Eliminate expensive trenching, cable pulling, and grid transformers for remote villages.

Highway Rest Areas & Toll Plazas

Continuous reliable perimeter and parking illumination with zero electricity bills.

Mining & Construction Camps

Rapidly deployable self-contained lighting assets that can be easily relocated.

Four-Gate Quality Control

Zero-Defect Export Assurance for LS-SOLAR-ST01

Every batch undergoes Incoming Quality Control (IQC), automated SMT optical validation, 48-hour high-temperature full-load aging tests, and Outgoing Quality Check (OQC) drop testing.

CE Compliant CB Certified RoHS Lead-Free 48h Aging Pass

GATE 01: IQC

Component Testing

100% LED chip forward voltage, CCT binning, and driver THD checks.

GATE 02: IPQC

Torque & Thermal Paste

Calibrated pneumatic screwdriver torque and automated solder paste printing.

GATE 03: 48H AGING

Thermal Stress Chamber

45°C constant temperature, 10,000 rapid on/off switching cycles.

GATE 04: OQC

Packaging & Hi-Pot

3,750V dielectric breakdown test and structural carton drop testing.

Direct Factory Inquiry

Request Quotation or Sample for LS-SOLAR-ST01

Get official Bill of Materials (BOM) cost breakdowns, sample availability, Dialux simulation files, or private label options within 24 hours directly from our Guzhen engineering office.

✓ Guaranteed 24-hour response by senior luminaire engineers

✓ Free Dialux 3D photometric calculation report for tender projects

✓ Prototype sample express dispatch via DHL / FedEx in 3-5 days
