IP69K Waterproof Farm & Specialized Tri-Proof Lighting
Home / Products / Agricultural & Tri-Proof Lighting

IP69K Waterproof Agricultural & Tri-Proof Lighting

Extreme-duty tubular LED luminaires engineered for poultry houses, swine breeding sheds, food processing facilities, and high-pressure chemical wash bays. Hermetically sealed PMMA shell resists ammonia (NH3) corrosion, hot steam sanitize cycles up to 100 bar, and delivers 0-100% flicker-free biological dimming.

IP69K Washdown
100 Bar / 80°C Steam Proof
Ammonia Proof
Corrosion-Free PMMA Tube
0.2% - 100% Dim
100% Flicker-Free Biological
Daisy-Chain Link
Quick Connect Through-Wiring
Explore Farm Series (Tabs) ↓ Request Shed Lighting Plan →
Extreme Industrial & Farming

Application Environments & Optical Form Factors

Built to survive the toughest conditions on earth: harsh organic acids, dense airborne dust, high humidity, caustic disinfectants, and daily sanitization procedures.

Poultry Broiler and Layer Barns Poultry Farming

Broiler & Layer Poultry Sheds

Chickens perceive light flicker up to 105 Hz. Our ultra-filtered DC drivers ensure zero flicker even at 0.2% moonlight dimming, preventing feather pecking and accelerating uniform weight gain.

Flicker Metric Zero Stroboscopic (SVM < 0.02)
Biological Spectrum Tuned Broiler / Layer Red-Green
Dimming Range 0.2% to 100% Smooth Trailing
Mounting Method Ceiling Clip / Wire Suspension
Swine and Pig Breeding Facilities Swine & Pig Farm

Pig & Swine Breeding Sheds

High ammonia (NH3) gas concentrations destroy conventional polycarbonate (PC) and aluminum within 6 months. Our seamless PMMA acrylic shell provides 10+ years of chemical immunity.

Chemical Immunity Ammonia (NH3) & Methane Proof
Housing Material Seamless Extruded PMMA Tube
Endcap Clamps 316 Marine Stainless Steel
Impact Strength IK10 Mechanical Resistance
Food Processing Cleanrooms and Abattoirs HACCP / Food Grade

Food Processing Plants & Abattoirs

Certified for food processing cleanrooms. Cylindrical smooth design eliminates ledges where bacteria, dust, or grease could accumulate, allowing complete clean-in-place sanitization.

Food Standard HACCP / IFS Hygienic Compliant
Cleaning Jet 100 Bar @ 80°C Steam Wash
Color Fidelity Ra ≥ 85 (Meat Inspection Grade)
Ingress Protection IP69K & IP66 Hermetic
Heavy Vehicle Wash Bays and Car Washes Commercial Wash Bay

Car Washes & Industrial Bays

Continuous 100% relative humidity, chemical soap foam, and accidental high-pressure water nozzle spray. Integrated breathable pressure valves prevent internal moisture condensation.

Relative Humidity 100% Continuous Non-Condensing
Detergent Proof Resistant to Alkaline Foams
Vent Membrane Gore-Tex Moisture Equalizer
Wiring Method Through-Wire Daisy Chain (5x2.5mm²)
Agricultural Engineering Rigor

DIN 40050-9 IP69K Certification & Ammonia Immunity

Tested in certified testing laboratories for high-pressure water jetting at 80°C and 100 bar pressure from four angles (0°, 30°, 60°, 90°) with turntable rotation.

Pure Extruded PMMA Shell
Unlike standard Polycarbonate (PC) which crazes and turns brittle under barn ammonia vapor, pure PMMA maintains its optical transparency and strength for over 50,000 hours.
Double-Silicone O-Ring Seal
Dual compression gaskets at both ends of the cylinder prevent microscopic water vapor migration during sudden temperature drops following hot sanitation washes.
Avian Biological LED Engine
Specialized monochromatic green/blue wavelengths (for chicks and early development) and 660nm deep red (to stimulate egg laying in mature layers) available on request.
Farm Luminaire Catalog

IP69K Agricultural & Tri-Proof Luminaires

Select series below to explore poultry biological tubes, heavy swine house battens, and food-grade stainless washdown luminaires. Click any model to view its dedicated 14-parameter page.

20W / 40W (1200mm) Flagship Farm Spec IP69K Waterproof Farm & Poultry Batten
Model: LS-AGRI-P20 · Flagship Tubular

IP69K Waterproof Farm & Poultry Batten

Ammonia-resistant PMMA tubular body, 316 stainless steel endcaps, 100-bar steam washdown proof, and 0-100% flicker-free biological dimming.

Wattage 20W (600mm) / 40W (1200mm)
Protection IP69K & IP66 Steam Proof
Chemical Proof Ammonia (NH3) Resistant PMMA
Dimming 0.2% - 100% Flicker-Free
MOQ: 50 Pcs
Lead Time: 12-16 Days
FOB: USD 18 - 36 / pc
View Full Specs & IES → Quick RFQ
50W (1500mm Long) High Sheds 1500mm High Lumen Poultry Batten
Model: LS-AGRI-P40 · 1500mm Long Batten

1500mm High-Lumen IP69K Poultry Batten

Delivering 6,500 lumens for large breeder sheds and multi-tier cage installations, reducing fixture count by 35% with quick-twist series linking.

Wattage 50W High Output (1500mm)
Luminous Flux 6,500 Lumens (130 lm/W)
Through-Wire 5x2.5mm² Quick Plug-in
Daisy Chain Up to 30 Pcs in One String
MOQ: 50 Pcs
Lead Time: 12-16 Days
FOB: USD 24 - 44 / pc
View Full Specs & IES → Quick RFQ
30W Ammonia-Guard Swine Spec Heavy Swine Livestock Tri-Proof
Model: LS-AGRI-SWINE · Ammonia Guard

Swine & Pig Breeding Shed Tri-Proof Batten

Thick-wall 4mm PMMA tube reinforced against gnawing and aggressive ammonia fog. Complete seal prevents toxic gas penetration into internal electronic drivers.

Wattage 30W / 45W Continuous
Gas Resistance NH3, H2S & CO2 Immunity
Tube Thickness 4.0mm Heavy Extrusion
Mounting Heavy 316 Stainless Straps
MOQ: 50 Pcs
Lead Time: 14-18 Days
FOB: USD 21 - 39 / pc
View Full Specs & IES → Quick RFQ
40W Cleanroom IP69K HACCP Food Grade Food Cleanroom Stainless Tubular Light
Model: LS-AGRI-HACCP · Cleanroom Tubular

HACCP Food Processing Stainless Tubular Luminaire

Smooth cylindrical crevice-free body designed for food production lines, dairy bottling rooms, and abattoirs. Resists corrosive chlorinated detergents.

Hygiene Standard HACCP / USDA Food Safe
Wattage 40W / 60W Option
Corrosion Level Acid & Alkali Detergent Proof
Color Index Ra ≥ 90 / R9 > 50 Inspection
MOQ: 50 Pcs
Lead Time: 14-18 Days
FOB: USD 26 - 48 / pc
View Full Specs & IES → Quick RFQ
Engineering Tailored to Livestock

Agricultural Spectrum & Wiring Customization

Optimize your shed illumination for maximum animal welfare, feed conversion ratio (FCR), and minimum maintenance.

🐔

Avian Biological Spectrum Tuning

Dual-channel white + deep 660nm red LED mixing to stimulate pineal gland ovulation in laying hens or monochromatic blue/green for calm broilers.

🔌

Toolless Fast-Plug Daisy Chaining

Waterproof IP68 quick-turn connector plugs pre-wired into endcaps allow contractors to install an entire 100-meter poultry shed in hours.

🌅

Dawn-to-Dusk Simulating Dimming

0-10V and trailing-edge dimming modules support 30-minute sunrise/sunset curve simulation to keep birds calm and stress-free.

🛡️

316 Marine Stainless End Caps

Upgrade from 304 to 316 marine-grade stainless steel hardware for intense marine aquaculture and high-salinity coastal farm environments.

Agricultural Project Engineering Desk

Request Poultry / Farm Shed Lighting Layout

Provide your barn dimensions (length × width × ceiling height) and livestock type. Our agricultural lighting engineers will simulate a Dialux shed lux layout and itemize all waterproof cables within 24 hours.

✓ Dialux 3D Lux Uniformity Simulation for Livestock Barns
✓ IP69K Hot Steam Test Certificates & CE / CB Test Reports
✓ 5-Year Comprehensive Commercial Warranty Coverage
✓ Guzhen Town Factory Direct FOB / CIF Volume Pricing
